| import sys
import gi
gi.require_version('Gst', '1.0')
gi.require_version('GstVideo', '1.0')
from gi.repository import Gst, GLib
def on_bus_message(bus, message, loop):
t = message.type
if t == Gst.MessageType.ERROR:
err, debug = message.parse_error()
print(f"Error: {err}", file=sys.stderr)
print(f"Debug Info: {debug}", file=sys.stderr)
loop.quit()
elif t == Gst.MessageType.EOS:
print("End-Of-Stream reached.")
loop.quit()
elif t == Gst.MessageType.STATE_CHANGED:
old, new, pending = message.parse_state_changed()
if old == Gst.State.NULL and new == Gst.State.READY:
print("Pipeline is preparing...")
elif t == Gst.MessageType.WARNING:
err, debug = message.parse_warning()
print(f"Warning: {err}", file=sys.stderr)
return True
def main():
Gst.init(None)
pipeline = Gst.Pipeline()
src = Gst.ElementFactory.make("v4l2src", "src")
converter = Gst.ElementFactory.make("videoconvert", "converter")
scaler = Gst.ElementFactory.make("videoscale", "scaler")
tee = Gst.ElementFactory.make("tee", "tee")
queue_display = Gst.ElementFactory.make("queue", "queue_display")
sink_display = Gst.ElementFactory.make("rkximagesink", "sink_display")
queue_rtsp = Gst.ElementFactory.make("queue", "queue_rtsp")
encoder = Gst.ElementFactory.make("mpph264enc", "encoder")
parser = Gst.ElementFactory.make("h264parse", "parser")
sink_rtsp = Gst.ElementFactory.make("rtspclientsink", "sink_rtsp")
if not src or not converter or not scaler or not tee or \
not queue_display or not sink_display or \
not queue_rtsp or not encoder or not parser or not sink_rtsp:
print("创建元素失败，请检查 GStreamer 插件是否安装完整。", file=sys.stderr)
sys.exit(1)
src.set_property("device", "/dev/video0")
scaler.set_property("add-borders", True)
sink_display.set_property("driver-name", "rockchip")
sink_rtsp.set_property("location", "rtsp://127.0.0.1:8554/live")
pipeline.add(src)
pipeline.add(converter)
pipeline.add(scaler)
pipeline.add(tee)
pipeline.add(queue_display)
pipeline.add(sink_display)
pipeline.add(queue_rtsp)
pipeline.add(encoder)
pipeline.add(parser)
pipeline.add(sink_rtsp)
caps_src = Gst.Caps.from_string("video/x-raw,width=1632,height=1224,framerate=30/1")
caps_scale = Gst.Caps.from_string("video/x-raw,width=1632,height=1232,format=NV12")
if not src.link_filtered(converter, caps_src):
print("链接 src -> converter 失败", file=sys.stderr)
sys.exit(1)
if not converter.link(scaler):
print("链接 converter -> scaler 失败", file=sys.stderr)
sys.exit(1)
if not scaler.link_filtered(tee, caps_scale):
print("链接 scaler -> tee 失败", file=sys.stderr)
sys.exit(1)
if not tee.link(queue_display):
print("链接 tee -> queue_display 失败", file=sys.stderr)
sys.exit(1)
if not queue_display.link(sink_display):
print("链接 queue_display -> sink_display 失败", file=sys.stderr)
sys.exit(1)
if not tee.link(queue_rtsp):
print("链接 tee -> queue_rtsp 失败", file=sys.stderr)
sys.exit(1)
if not queue_rtsp.link(encoder):
print("链接 queue_rtsp -> encoder 失败", file=sys.stderr)
sys.exit(1)
if not encoder.link(parser):
print("链接 encoder -> parser 失败", file=sys.stderr)
sys.exit(1)
if not parser.link(sink_rtsp):
print("链接 parser -> sink_rtsp 失败", file=sys.stderr)
sys.exit(1)
loop = GLib.MainLoop()
bus = pipeline.get_bus()
bus.add_signal_watch()
bus.connect("message", on_bus_message, loop)
print("Starting pipeline...")
ret = pipeline.set_state(Gst.State.PLAYING)
if ret == Gst.StateChangeReturn.FAILURE:
print("无法启动 Pipeline", file=sys.stderr)
loop.quit()
try:
loop.run()
except KeyboardInterrupt:
pass
pipeline.set_state(Gst.State.NULL)
if __name__ == "__main__":
main()
|
